Part Number: SST12LN01

Manufacturer: Microchip

Category: Wireless

Description: Applications: • WLAN • Bluetooth • Wireless Network

Part Number: SST12LF03

Manufacturer: Microchip

Category: Wireless

Description: Transmitter Chain: • High gain: – Typically 28 dB gain across 2.4–2.5 GHz over temperature -20°C to +85°C for Transmitter. • High linear output power: – Meets 802.11g OFDM ACPR requirement up to 21 dBm – 3% added EVM up to 19 dBm for 54 Mbps 802.11g signal – Meets 802.11b ACPR requirement up to 22 dBm • High power-added efficiency/Low operating current for 802.11b/g/n applications – ~25% @ POUT = 22 dBm for 802.11b/g Receiver Chain: • LNA ON: – Typically 12 dB gain – 3.1 dB noise figure – >5dB P1dB Bluetooth Path: • Typically 2.5 dB loss Applications: • WLAN (IEEE 802.11b/g/n) • Home RF • Cordless phones • 2.4 GHz ISM wireless equipment • Zigbee® • Bluetooth®

Part Number: SST11LP12

Manufacturer: Microchip

Category: Wireless

Description: High gain High linear output power: – Meets 802.11a OFDM Spectrum Mask requirements up to 24 dBm over the entire band – Added EVM <3% up to 20 dBm for 54 Mbps 802.11a signal – Meets 802.11n HT40 Spectrum Mask requirements typically up to 20 dBm High power-added efficiency/Low operating current for 6 Mbps 802.11a applications – ~17% @ POUT = 23 dBm for 6 Mbps Simple input/output matching Applications: WLAN (IEEE 802.11a/n) Japan WLAN HyperLAN2 Multimedia

Part Number: SST11CP15E

Manufacturer: Microchip

Category: Wireless

Description: High linear output power, 802.11a/n/ac: – Added EVM ~3% across 5.1-5.9 GHz for 54 Mbps 802.11a - Up to 19.5 dBm at 5.0V VCC - Up to 17.5 dBm at 3.3V VCC - 16 dBm at 1.8% EVM, 802.11ac, 256 QAM, 5GHz 5.0V VCC 50O on-chip input match and simple output match APPLICATIONS: • WLAN (IEEE 802.11a/n/ac) • Japan WLAN • HyperLAN2 • Multimedia

Part Number: SST12LP17E

Manufacturer: Microchip

Category: Wireless

Description: Input/Output ports internally matched to 50O and DC decoupled High gain:– Typically 28 dB gain across 2.4–2.5 GHz >24 dBm P1dB– Meets 802.11g OFDM ACPR requirement up to 21.5 dBm ~3% added EVM up to 18 dBm for 54 Mbps 802.11g signal Meets 802.11b ACPR requirement up to 22 dBm ~28%/138 mA @ POUT = 21.5 dBm for 802.11g ~33%/155 mA@POUT = 22.5 dBm for 802.11bAPPLICATIONS WLAN (IEEE 802.11b/g/n) Home RF Cordless phones 2.4 GHz ISM wireless equipment

Part Number: SST12LP15B

Manufacturer: Microchip

Category: Wireless

Description: High Gain: – More than 32 dB gain across 2.4–2.5 GHz over temperature -40°C to +85°C High linear output power: – >29 dBm P1dB – Meets 802.11g OFDM ACPR requirement up to 26 dBm – ~3% added EVM up to 23 dBm for 54 Mbps 802.11g signal – Meets 802.11b ACPR requirement up to 25.5 dBm High power-added efficiency/Low operating current for 802.11b/g/n applications Applications WLAN (IEEE 802.11b/g/n) Home RF Cordless phones 2.4 GHz ISM wireless equipment

Part Number: SST12LP15A

Manufacturer: Microchip

Category: Wireless

Description: High Gain: – Typically 32 dB gain across 2.4–2.5 GHz over temperature 0°C to +85°C High linear output power: – >29 dBm P1dB – Meets 802.11g OFDM ACPR requirement up to 25 dBm – Added EVM~4% up to 23 dBm for 54 Mbps 802.11g signal – Meets 802.11b ACPR requirement up to 25 dBm High power-added efficiency/Low operating current for both 802.11g/b applications – ~26%/300 mA @ POUT = 24 dBm for 802.11g – ~27%/350 mA @ POUT = 25 dBm for 802.11b Applications: WLAN (IEEE 802.11b/g/n) Home RF Cordless phones 2.4 GHz ISM wireless

Part Number: SST12CP11C

Manufacturer: Microchip

Category: Wireless

Description: High Gain:- Typically 37 dB gain across 2.4–2.5 GHz over temperature -20°C to +85°C>30 dBm P1dBMeets 802.11g OFDM spectrum mask requirement up to 28 dBmMeets 802.11b ACPR requirement up to 28 dBmTypically 25 dBm with <3% EVM, 802.11g,54 MbpsTypically 24 dBm with <2.5% EVM, 802.11n,MCS7-HT20, 50% duty cycleTypically 24 dBm with <1.75% EVM, MCS9HT40,50% duty cycle Packages available- 16-contact UQFN (3mm x 3mm)- Pin-to-pin compatible with SST12CP11-Applications WLAN (IEEE 802.11b/g/n) WLAN 256 QAM AP router WiMax (IEEE 802.16e) Home RF Cordless phones 2.4 GHz ISM wireless equipment
